Powering options:

4-pin power socket 9-30 VDC

Ethernet:

4 x 10/100 Mbps Ethernet ports

1 x WAN (configurable as LAN)

3 x LAN

Interfaces:

1 x RS232; 1 x RS485; 1 x USB host

On 4-pin socket:

1 x Digital input

1 x Digital open collector output

On 10-pin socket:

1 x Isolated digital input

1 x Digital dry input

1 x Analog input

1 x Isolated open collector output

(requires external voltage)

1 x Relay output (non-latching);GNSS

Wi-Fi:

IEEE 802.11b/g/n, Access point (AP)

Station (STA)

Housing & mounting:

Aluminium housing with DIN rail

mounting option, plastic panels

with flat mounting option

Measurement:

110 x 50 x 100 mm
